PCB Terminal Block KF250B-3.50mm
Terminal Material：①Button：PA66，UL94V-0②Cover：PA66，UL94V-0③Button：PA66，UL94V-0④Pin headerA：Brass，Tin plated⑤Pin headerB：Brass，Tin platedElectricalULIECRated voltage300V 450V Rated current7A9AContact resistance20mΩInsulation resistance500MΩ/DC500VWithstanding voltage AC2000V/1minWire range24-18AWG 0.75mm2MechanlicalTemp.rang-40℃～+105℃
Color
  • Kaifeng Electron
Line count
  • 01P
  • 02P
  • 03P
  • 04P
  • 05P
  • 06P
  • 07P
  • 08P
  • 09P
  • 10P
  • 11P
  • 12P
  • 13P
  • 14P
  • 15P
  • 16P
  • 17P
  • 18P
  • 19P
  • 20P
  • 21P
  • 22P
  • 23P
  • 24P
Product Drawing Material Electrical Mechanical
Product Drawing
Kaifeng Electron
Material
  • Button
    PA66，UL94V-0
  • Cover
    PA66，UL94V-0
  • Button
    PA66，UL94V-0
  • Pin headerA
    Brass, Tin plated
  • Pin headerB
    Brass, Tin plated
Electrical
  • Rated voltage
    300V UL丨 450V lEC
  • Rated current
    7A UL丨 9A lEC
  • Contact resistance
    20mΩC
  • Insulation resistance
    500MΩ\DC500V
  • Withstanding voltage
    AC2000V\1Min
  • Wire range
    24-18AWG 0.75mm2
Mechanical
  • Temp.rang
    LOW-40℃ 丨TOP+105℃
  • Max.soldering
    +250℃, 5秒
  • Strip length
    8-9mm
