Pluggable Terminal Block KF5EKM-10.16mm

Pluggable Terminal Block MATERIAL：Screws:M4.0Steel Zinc platedHousing:PA66,UL94V-0contact：Red copperSquare:Brass, Tin platedElectricalULIECRated voltage600V600VRated current52A57AContact resistance20m?(Max)Insulation resistance500MΩ\DC500VWithstanding voltage AC6000V\1MinWire range20-7AWG0.5-10.0mm2MechanicalTemp.rang-40℃～+150℃Max.soldering+250℃，5secTorque1.2N.m10.53Lb.inStrip length12m

Color
