PCB Terminal Block KF136HT-10.16mm

PCB Terminal Block MATERIAL：MATERIAL①Screws:M4.0Steel Zinc plated,"-"slot type②Housing:PA66,UL94V-0③square box：Red copper，Ni plated④Pin header:Brass, Tin platedELECTRICALULIECRated voltage600V1000VRated current65A65AContact resistance20m?(Max)Insulation resistance500MΩ\DC500VWithstanding voltage AC3000V\1MinWire range20-6AWG16.0mm2MechanicalTemp.rang-40℃～+105℃Max.soldering+250℃，5secTorque1.2

Color
