Pluggable Terminal Block KF12EDM-3.50mm

Pluggable Terminal Block MATERIAL：①Screws：M2.0,Steel Zinc plated②Reed : Stainless steel③Clip : Phosphor bronze，Tinning ④Button : PA66，UL94V-0 ⑤Housing : PA66，UL94V-0 ⑥Cover : PA66，UL94V-0

Color
